KCD2-E2L - 018358

Sensör Çıkış Arayüzü Terminali

Öne Çıkan Özellikler

➤ 1-channel terminal amplifier

➤ NAMUR sensor input

➤ DC 24 V supply voltage

➤ Standard interface for prevention of signal transmission errors

➤ Switching status indicator, yellow LED

➤ Lead breakage monitoring: The lead breakage monitoring can be disconnected by bridging terminals 1 and 3

➤ Short-circuit proof electronic output

➤ Low noise sensitivity

➤ Compact terminal housing

➤ Clips onto standard 35 mm rail to DIN EN 50 022

➤ Degree of protection IP20
